HI耐衝擊PVC-U塑膠管
通過公立大學耐震試驗,HI耐衝擊PVC-U塑膠管適用於空調管、給水管、冰水管、電線導管、空調冷凍水配管工程及山區自來水配管等用途。
敬請電洽+886-2-27122211- 具有良好的可撓性、高耐震性,耐衝擊、強度良好。
- 耐酸、耐鹼、耐腐蝕性,適用於化學工業配管。
- 管內壁光滑,對流體之阻力小,其粗糙係數僅0.009較其他管材為低,不易附著水垢,與同口徑之金屬管比較,其流量較大。
- 耐水壓強度、耐外壓強度,適用於各種配管工程。
- 不影響水質。
HI耐衝擊PVC-U塑膠管產品之特性
- 1.地震頻繁地區之給水管、排水管、電線導管。
- 2.交通流量頻繁道路之自來水管、排水管、電線導管。
- 3.空調冷凍水配管工程之空調管、冰水管。
HI耐衝擊PVC-U塑膠管產品用途
HI耐衝擊PVC-U塑膠管相關影片
HI耐衝擊PVC-U塑膠管規格表
標稱管徑 | 平均外徑 | 近似內徑 | 最小厚度 | 長度 | 有效長度 | 每支牌價 | |
---|---|---|---|---|---|---|---|
HIW,HIB40 | 1 1/2" | 48mm | 40mm | 3.7mm | 7.15m | 7m | 1,060.7 |
HIW,HIB50 | 2" | 60mm | 51mm | 4.1mm | 1,507.3 | ||
HIW,HIB65 | 2 1/2" | 76mm | 67mm | 4.1mm | 1,945.4 | ||
HIW,HIB80 | 3" | 89mm | 77mm | 5.5mm | 3,000.6 | ||
HIW,HIB100 | 4" | 114mm | 100mm | 6.6mm | 7.17m | 7m | 4,671.3 |
HIW125 | 5" | 140mm | 125mm | 7.0mm | 7.2m | 6,573.4 | |
HIW,HIB150 | 6" | 165mm | 146mm | 9.0mm | 7.22m | 9,238.1 | |
HIW,HIB200 | 8" | 216mm | 194mm | 10.8mm | 7.25m | 14,288.4 | |
HIW,HIB250 | 10" | 267mm | 239mm | 13.3mm | 7.3m | 22,367.4 | |
HIW,HIB300 | 12" | 318mm | 285mm | 15.9mm | 7.5m | 7m | 32,002.0 |
HIW,HIB350 | 14" | 370mm | 332mm | 18.0mm | 7.55m | 43,295.2 | |
HIW,HIB400 | 16" | 420mm | 376mm | 20.5mm | 7.6m | 56,014.5 |
標稱管徑 | 平均外徑 | 近似內徑 | 最小厚度 | 長度 | 有效長度 | 每支牌價 | |
---|---|---|---|---|---|---|---|
HIW,HIB40 | 1 1/2" | 48mm | 40mm | 3.7mm | 7.22m | 7m | 1,056.1 |
HIW,HIB50 | 2" | 60mm | 51mm | 4.1mm | 7.225m | 1,502.2 | |
HIW,HIB65 | 2 1/2" | 76mm | 67mm | 4.1mm | 1,925.3 | ||
HIW,HIB80 | 3" | 89mm | 77mm | 5.5mm | 2,943.7 | ||
HIW,HIB100 | 4" | 114mm | 100mm | 6.6mm | 7.24m | 4,567.0 | |
HIW125 | 5" | 140mm | 125mm | 7.0mm | 7.25m | 7m | 6,440.2 |
HIW,HIB150 | 6" | 165mm | 146mm | 9.0mm | 7.255m | 8,996.4 | |
HIW,HIB200 | 8" | 216mm | 194mm | 10.8mm | 7.275m | 14,223.6 | |
HIW,HIB250 | 10" | 267mm | 239mm | 13.3mm | 7.295m | 20,891.5 | |
HIW,HIB300 | 12" | 318mm | 285mm | 15.9mm | 7.315m | 31,119.6 | |
HIW,HIB350 | 14" | 370mm | 332mm | 18.0mm | 7.34m | 7m | 41,271.0 |
HIW,HIB400 | 16" | 420mm | 376mm | 20.5mm | 7.36m | 53,540.5 |
標稱管徑 | 平均外徑 | 近似內徑 | 最小厚度 | 長度 | 有效長度 | 每支牌價 | |
---|---|---|---|---|---|---|---|
HIW,HIB40 | 1 1/2" | 48mm | 40mm | 3.7mm | 4.11m | 4m | 601.1 |
HIW,HIB50 | 2" | 60mm | 51mm | 4.1mm | 4.13m | 858.6 | |
HIW,HIB65 | 2 1/2" | 76mm | 67mm | 4.1mm | 4.14m | 1,103.2 | |
HIW,HIB80 | 3" | 89mm | 77mm | 5.5mm | 4.15m | 1,694.2 | |
HIW,HIB100 | 4" | 114mm | 100mm | 6.6/m | 5.165m | 5m | 3,260.4 |
HIW125 | 5" | 140mm | 125mm | 7.0mm | 5.18m | 4,601.4 | |
HIW,HIB150 | 6" | 165mm | 146mm | 9.0mm | 6.205m | 6m | 7,694.4 |
HIW,HIB200 | 8" | 216mm | 194mm | 10.8mm | 6.24m | 11,887.9 | |
HIW,HIB250 | 10" | 267mm | 239mm | 13.3mm | 6.285m | 18,376.3 | |
HIW,HIB300 | 12" | 318mm | 285mm | 15.9mm | 6.325m | 26,287.4 | |
HIW,HIB350 | 14" | 370mm | 332mm | 18.0mm | 6.36 | 35,760.7 | |
HIW,HIB400 | 16" | 420mm | 376mm | 20.5mm | 6.385M | 6m | 46,448.5 |
HIW,HIB450 | 18" | 470mm | 422mm | 22.9mm | 6.42m | 58,448.4 | |
HIW,HIB500 | 20" | 520mm | 467mm | 25.3mm | 71,950.0 | ||
HIW,HIB600 | 24" | 630mm | 566mm | 30.7mm | 6.55m | 106,290.4 |
標稱管徑 | 平均外徑 | 近似內徑 | 最小厚度 | 長度 | 每支牌價 | |
---|---|---|---|---|---|---|
HIW,HIB13 | 3/8" | 18mm | 13mm | 2.2mm | 4m | 122.4 |
HIW,HIB16 | 1/2" | 22mm | 16mm | 2.7mm | 180.7 | |
HIW,HIB20 | 3/4" | 26mm | 20mm | 2.7mm | 218.2 | |
HIW25 | 1" | 32mm | 25mm | 3.2mm | 316.1 | |
HIW30 | 1 1/4" | 38mm | 31mm | 3.2mm | 382.3 | |
HIW,HIB40 | 1 1/2" | 48mm | 40mm | 3.7mm | 557.3 | |
HIW,HIB50 | 2" | 60mm | 51mm | 4.1mm | 792.0 | |
HIW,HIB65 | 2 1/2" | 76mm | 67mm | 4.1mm | 1,015.2 | |
HIW,HIB80 | 3" | 89mm | 77mm | 5.5mm | 1,555.2 | |
HIW,HIB100 | 4" | 114mm | 100mm | 6.6mm | 5m | 3,006.0 |
HIW125 | 5" | 140mm | 125mm | 7.5mm | 4,230 | |
HIW,HIB150 | 6" | 165mm | 146mm | 9.0mm | 6m | 7,085.9 |
HIW,HIB200 | 8" | 216mm | 195mm | 10.5mm | 10,886.4 | |
HIW,HIB250 | 10" | 267mm | 241mm | 13.0mm | 16,707.6 | |
HIW,HIB300 | 12" | 318mm | 287mm | 15.5mm | 23,749.2 | |
HIW,HIB350 | 14" | 370mm | 332mm | 18.0mm | 32,130.0 | |
HIW,HIB400 | 16" | 420mm | 376mm | 20.5mm | 41,569.2 | |
HIW,HIB450 | 18" | 470mm | 422mm | 22.9mm | 52,023.6 | |
HIW,HIB500 | 20" | 520mm | 467mm | 25.3mm | 63,644.4 | |
HIW,HIB600 | 24" | 630mm | 566mm | 30.7mm | 92,728.8 |
