南亞CNS規範-UPVC塑膠管
品質優良符合國際水準，擁有台灣規模最龐大，最新式的塑膠管生產設備，其產能高居台灣之冠。
且接頭規格齊全，搭配使用可確保施工後管路品質。
敬請電洽+886-2-27178230
- UPVC管材質輕，搬運、裝卸、施工便利，可節省人工。
- 耐酸、耐鹼、耐腐蝕性佳，適用於化學工業配管。
- 管壁光滑，對流體之阻力小，其粗糙係數僅0.009較其他管材為低，相同管徑下，流量較其他材質大。
- 耐水壓強度、耐外壓強度、耐衝擊強度良好，適用於各種配管工程。
- 電氣絕緣性，可作為電線、電纜之導管。
- 溶解試驗證實南亞UPVC管不影響水質，為目前自來水配管之最佳管材。
CNS規範-UPVC塑膠管
- 1.自來水工程。
- 2.電氣工程。
- 3.建築工程。
- 4.下水道工程。
- 5.電信工程。
- 6.鑿井工程。
- 7.漁業用塑膠筏。
CNS規範-UPVC塑膠管產品用途
CNS規範-UPVC管相關影片
CNS規範-UPVC管規格表
| 標稱管徑 | 平均外徑 | 近似內徑 | 最小厚度 | 長度 | 每米牌價 | 每支牌價 | |
|---|---|---|---|---|---|---|---|
| W13 | 3/8" | 18mm | 13mm | 2.3mm | 4m | 9.00 | 36.00 |
| W16 | 1/2" | 22mm | 16mm | 2.7mm | 12.90 | 51.60 | |
| W20 | 3/4" | 26mm | 20mm | 2.7mm | 15.60 | 62.40 | |
| W25 | 1" | 32mm | 25mm | 3.2mm | 22.58 | 90.30 | |
| W30 | 11/4" | 38mm | 31mm | 3.2mm | 27.25 | 109.00 | |
| W40 | 11/2" | 48mm | 40mm | 3.7mm | 40.45 | 161.80 | |
| W50 | 2" | 60mm | 51mm | 4.1mm | 56.65 | 226.60 | |
| W65 | 21/2" | 76mm | 67mm | 4.1mm | 72.90 | 291.60 | |
| W80 | 3" | 89mm | 77mm | 5.5mm | 110.10 | 440.40 | |
| W100 | 4" | 114mm | 100mm | 6.6mm | 5m | 171.00 | 855.00 |
| W125 | 5" | 140mm | 125mm | 7.0mm | 223.20 | 1,116.00 | |
| W150 | 6" | 165mm | 146mm | 9.0mm | 6m | 335.10 | 2,010.60 |
| W200 | 8" | 216mm | 194mm | 10.8mm | 527.95 | 3,167.70 | |
| W250 | 10" | 267mm | 239mm | 13.3mm | 805.95 | 4,835.70 | |
| W300 | 12" | 318mm | 284mm | 15.9mm | 1,148.80 | 6,892.80 | |
| W350 | 14" | 370mm | 332mm | 18.0mm | 1,526.00 | 9,156.00 | |
| W400 | 16" | 420mm | 376mm | 20.5mm | 1,974.00 | 11,844.00 | |
| W450 | 18" | 470mm | 421mm | 22.9mm | 2,470.00 | 14,820.00 | |
| W500 | 20" | 520mm | 466mm | 25.3mm | 3,022.00 | 18,132.00 | |
| W600 | 24" | 630mm | 565mm | 30.7mm | 4,403.5 | 26,421.00 | |
| 標稱管徑 | 平均外徑 | 近似內徑 | 最小厚度 | 長度 | 有效長度 | 每支牌價 | |
|---|---|---|---|---|---|---|---|
| 13 | 3/8" | 18mm | 14mm | 1.8mm | 4m | 7.23 | 28.90 |
| 16 | 1/2" | 22mm | 18mm | 9.05 | 36.20 | ||
| 20 | 3/4" | 26mm | 22mm | 10.85 | 43.40 | ||
| 28 | 1" | 34mm | 28mm | 2.7mm | 21.03 | 84.10 | |
| 35 | 11/4" | 42mm | 35mm | 3.1mm | 30.48 | 121.90 | |
| 41 | 11/2" | 48mm | 41mm | 35.20 | 140.80 | ||
| 52 | 2" | 60mm | 52mm | 3.6mm | 50.63 | 202.50 | |
| 65 | 21/2" | 76mm | 67mm | 4.1mm | 72.90 | 291.60 | |
| 80 | 3" | 89mm | 78mm | 5.1mm | 104.05 | 416.20 | |
| 100 | 4" | 114mm | 100mm | 6.6mm | 5m | 171.00 | 855.00 |
| 125 | 5" | 140mm | 125mm | 7.0mm | 223.20 | 1,116.00 | |
| 150 | 6" | 165mm | 148mm | 8.5mm | 323.00 | 1,615.00 | |
| E200 | 8" | 216mm | 194mm | 10.5mm | 6M | 517.00 | 3,102.00 |
| ES-1 80 | 3" | 89mm | 83mm | 2.7mm | 4m | 58.50 | 234.00 |
| ES-1 100 | 4" | 114mm | 106mm | 3.6mm | 5m | 103.00 | 515.00 |
| ES-1 125 | 5" | 140mm | 131mm | 4.1mm | 138.10 | 690.50 | |
| ES-1 150 | 6" | 165mm | 154mm | 5.1mm | 198.68 | 993.40 | |
| 標稱管徑 | 平均外徑 | 近似內徑 | 最小厚度 | 長度 | 有效長度 | 每支牌價 | |
|---|---|---|---|---|---|---|---|
| 筏125 | 5" | 140mm | 133mm | 3.3mm | 5m | 108.20 | 541.00 |
| 筏150 | 6" | 165mm | 257mm | 3.7mm | 145.86 | 729.30 | |
| 筏200 | 8" | 216mm | 206mm | 4.6mm | 6m | 238.70 | 1,432.20 |
| 筏250 | 10" | 267mm | 253mm | 6.6mm | 411.70 | 2,470.20 | |
| 筏300 | 12" | 318mm | 301mm | 8.0mm | 593.02 | 3,558.10 | |
| 筏350 | 14" | 370mm | 350mm | 9.3mm | 811.50 | 4,869.00 | |
| 筏400 | 16" | 420mm | 396mm | 11.2mm | 1,104.00 | 6,624.00 | |
| 筏450 | 18" | 470mm | 442mm | 13.1mm | 1,439.5 | 8,637.00 | |
| 標稱管徑 | 平均外徑 | 近似內徑 | 最小厚度 | 長度 | 每米牌價 | 每支牌價 | |
|---|---|---|---|---|---|---|---|
| A40 | 11/2" | 48mm | 44mm | 1.8mm | 4m | 20.80 | 83.20 |
| A50 | 2" | 60mm | 56mm | 1.8mm | 26.23 | 104.90 | |
| A65 | 21/2" | 76mm | 71mm | 2.2mm | 41.25 | 165.00 | |
| A80 | 3" | 89mm | 83mm | 2.7mm | 58.50 | 234.00 | |
| A90 | 31/2" | 100mm | 94mm | 3.1mm | 73.80 | 295.20 | |
| A100 | 4" | 114mm | 107mm | 3.1mm | 88.00 | 352.00 | |
| A125 | 5" | 140mm | 131mm | 4.1mm | 5m | 138.10 | 690.50 |
| A150 | 6" | 165mm | 154mm | 5.1mm | 198.68 | 993.40 | |
| A200 | 8" | 216mm | 202mm | 6.5mm | 6M | 331.44 | 1,988.60 |
| A250 | 10" | 267mm | 250mm | 7.8mm | 497.76 | 2,986.60 | |
| A300 | 12" | 318mm | 298mm | 9.2mm | 697.73 | 4,186.40 | |
| A350 | 14" | 370mm | 348mm | 10.5mm | 906.00 | 5,436.00 | |
| A400 | 16" | 420mm | 395mm | 11.8mm | 1,157.50 | 6,945.00 | |
| A450 | 18" | 470mm | 442mm | 13.2mm | 1,449.50 | 8,697.00 | |
| A500 | 20" | 520mm | 491mm | 14.6mm | 1,767.30 | 10,603.80 | |
| A600 | 24" | 630mm | 595mm | 17.8mm | 2,633.95 | 15,803.70 | |
| B13 | 3/8" | 18mm | 13mm | 2.3mm | 4m | 9.00 | 36.00 |
| B16 | 1/2" | 22mm | 16mm | 2.7mm | 12.90 | 51.60 | |
| B20 | 3/4" | 26mm | 20mm | 2.7mm | 15.60 | 62.40 | |
| B40 | 11/2" | 48mm | 40mm | 3.6mm | 39.55 | 158.20 | |
| B50 | 2" | 60mm | 51mm | 4.1mm | 56.65 | 226.60 | |
| B65 | 21/2" | 76mm | 67mm | 4.1mm | 72.90 | 291.60 | |
| B80 | 3" | 89mm | 77mm | 5.5mm | 110.10 | 440.40 | |
| B100 | 4" | 114mm | 100mm | 6.6mm | 5m | 171.00 | 855.00 |
| B125 | 5" | 140mm | 125mm | 7.0mm | 223.20 | 1,116.00 | |
| B150 | 6" | 165mm | 146mm | 8.9mm | 6M | 335.05 | 2,010.30 |
| B200 | 8" | 216mm | 194mm | 10.3mm | 506.50 | 3,039.00 | |
| B250 | 10" | 267mm | 241mm | 12.7mm | 774.50 | 4,647.00 | |
| B300 | 12" | 318mm | 286mm | 15.1mm | 1,098.50 | 6,591.00 | |
| B350 | 14" | 370mm | 332mm | 18.0mm | 1,526.00 | 9,156.00 | |
| B400 | 16" | 420mm | 376mm | 20.5mm | 1,974.00 | 11,844.00 | |
| B450 | 18" | 470mm | 421mm | 22.9mm | 2,470.00 | 14,820.00 | |
| B500 | 20" | 520mm | 466mm | 25.3mm | 3,022.00 | 18,132.00 | |
| B600 | 24" | 630mm | 565mm | 30.7mm | 4,403.50 | 26,421.00 | |
